Norfolk Oak Chevron
- Wear layer 0.55mm
- Waterproof 100%
- Underfloor heating Up to 27°C
- Warranty Lifetime domestic
A light natural oak with a soft greige cast, visible knots and a fine grain, calm and easy to pair with creams, blues and pale timber furniture. Luvanto Premium Design chevron in 135 x 538mm glue-down blocks with angled ends. Chelsea Oak and Norfolk Oak.
Norfolk Oak is also available as
£59.99£71.99 per m²
How much do I need?
Work it out from length × width
0 packs covers 0m²
Total
- Questions? Call 01484 411888
- Delivery information
- Classic chevron point
- Makes rooms feel longer
- Matching plank and herringbone
- 100% waterproof
- Lifetime domestic warranty
To finish the job
Product information
Norfolk Oak
A light natural oak with a soft greige cast, visible knots and a fine grain, calm and easy to pair with creams, blues and pale timber furniture.
Chevron blocks have angled ends that meet in a point, giving a crisp, continuous zigzag that draws the eye down a room. Luvanto suggests laying it pointing away from the room's main light source to make the space feel larger. Each block has slight differences in shade and markings, so every chevron floor looks a little different depending on the laying order.
Choose honey-toned Chelsea Oak or light, natural Norfolk Oak. Both also come as Premium Design planks and herringbone. The blocks are 135 x 538mm in 2.5mm dryback LVT with an embossed grain and bevelled edges.
Key facts
- Block size 135 x 538mm, 1.25m² per pack
- Thickness 2.5mm, wear layer 0.55mm, PU surface finish
- 100% waterproof, R10 slip rating, Bfl-s1 fire rating
- Suitable for underfloor heating up to 27°C
- Rated for heavy domestic (Class 23) and heavy commercial (Class 33) use
- Manufacturer's warranty: Lifetime domestic, 10 years commercial
Premium Design chevron is a glue-down floor and should be fitted by a professional to BS8203 using Luvanto Universal or High Temperature Adhesive.
Before you start
- The subfloor must be smooth, clean, dry (below 75% RH) and flat to within 3mm over 2m, which usually means primer and a smoothing compound; timber floors are overlaid with plywood first.
- Unpack the flooring and stack it flat in the room for 48 hours at 18 to 21°C, or 72 hours if it has been stored somewhere cold.
- Underfloor heating should be off for 48 hours before, during and after fitting.
- Chevron needs careful setting out so the points line up, so it’s a job for an experienced fitter.
- Delivered on a pallet Flooring is heavy, so it comes palletised to the kerbside. You’ll need to move it from the roadside into the property.
- We confirm the day Deliveries run Monday to Friday, 8am to 6pm. We’ll confirm your date once the order is processed. We can’t offer timed slots.
- Check before you sign Someone needs to be in to sign for it. Look over the packs first and tell us within 24 hours if anything is damaged.
- Book your fitter afterwards Wait until your flooring has arrived before booking a fitter. We can’t cover fitter costs if a delivery is held up.
Delivery costs show in your basket. UK mainland only: call us for anywhere else. Full delivery information
Technical information
| Product code | QAF-LVC-02 |
|---|---|
| Coverage | 1.25m² per pack |
| Brand | Luvanto |
| Colour | Norfolk Oak |
| Style | Chevron |
| Thickness | 2.5mm |
| Range | Luvanto Premium Design |
| Fitting | Glue down (dryback) |
| Size | 135 × 538mm |
| Warranty | Lifetime domestic, 10 years commercial |
| Use class | 23 heavy domestic / 33 heavy commercial |
| Wear layer | 0.55mm |
| Weight | 4.55kg/m² |
| Surface treatment | PU |
| Sound reduction | 4dB |
| Slip resistance | R10 |
| Fire rating | Bfl-S1 |
| Waterproof | 100% |
| VOC emission | A+ |
| Underfloor heating | Suitable, max 27°C |
| Thermal resistance | 0.0112 m²K/W |
| Pack | 1.25m² |
| Pallet | 140 packs |
Specifications are the manufacturer’s and may change. Please check the fitting guide before you start.
More colours in Luvanto Premium Design Chevron
Frequently asked questions
Which way should the chevron point?
Luvanto recommends laying it pointing away from the room's natural light source, which makes the space look larger.
How many packs do I need?
Each pack covers 1.25m². Measure the room in square metres, add around 10% for cuts, a bit more for chevron, divide by the pack coverage and round up.
Can I fit it myself?
Luvanto recommends professional installation for its glue-down ranges, and the warranty requires the floor to be laid by a fitter with at least an NVQ Level 2 in flooring, to BS8203, using Luvanto adhesive. If you'd like to fit a floor yourself, the Click Plus ranges are designed for that.
Is it suitable for underfloor heating?
Yes. The heating must keep the temperature at the adhesive below 27°C and be commissioned before fitting. Once the floor is down, bring the heating back up gradually over at least seven days.
Can I use it in a kitchen or bathroom?
Yes, it's 100% waterproof and has an R10 slip rating. Luvanto says it shouldn't be fitted outdoors or anywhere that's continuously wet, such as inside a shower.
